2 Models Available
MiniTest 70F – Ferrous Only Model
MiniTest 70FN – Combination Ferrous & Non-Ferrous Model
The MiniTest 70 is a pocket sized, versatile and accurate thickness gauge with built-in sensor. Especially designed for easy operation, this gauge is the ideal tool to measure any non-magnetic coatings on steel and/or any insulating layers on non-ferrous metals.
Coating thickness gauges designed for measurement on non-ferrous metals can measure insulating coatings such as paint, enamels, anodic films, etc, on non-ferrous metal bases such as aluminium, copper, brass, etc. The spring-mounted sensors are equipped with wear-resistant sensor poles and ensure durability even when used for measurements on rough and abrasive substrates.
With coating thickness gauges designed for measurement on ferrous metals, non-magnetic coatings such as paint, enamels, chrome, etc., can be measured on ferro-magnetic bases such as constructional steel, car bodies, etc.
The MiniTest 70 Series provides accurate, non-destructive coating measurements on steel and non-ferrous metals (FN model). Also, the FN model is equipped with a dual sensor for automatic identification of the substrate. According to the substrate, it adjusts to the appropriate measuring principle: magnetic induction or eddy currents principle. Both models are provided with a quick statistics mode to calculate the number of readings, average, standard deviation and min./ max. value which makes the MiniTest 70 ideal for on-site operations.
Features
- Pocket sized, compact coating thickness gauge
- Proven measuring methods
- Statistics function
- High repeatability
- For fast and precise measurements of non-magnetic coatings on steel and insulating coatings on non-ferrous metals
- Enables 1-point and 2-point calibrations
- Automatic identification of the substrate material
- Built-in sensor
– MiniTest 70 F or FN – Steel and aluminium test plates (for model 70FN)
– Calibration foils
– Operating instructions
– Gauge tether
– Belt pouch
Specifications
| Measuring Range | MiniTest 70F – 0 – 3 mm (0 – 120 mils) MiniTest 70FN – F: 0 – 3 mm (0 – 120 mils) / N: 0 – 2.5mm (0 – 100 mils) |
| Measuring Principle | MiniTest 70F – magnetic induction MiniTest 70FN – magnetic induction / eddy currents |
| Signal Processing | Sensor integrated 32-bit signal processing (SIDSP®) |
| Accuracy | ± (1.5 µm + 3 % of reading) with 1-point calibration ± (1.5 µm + 2% of reading) with 2-point calibration |
| Repeatability | ± (1 µm + 1 % of reading) ± (0.04 mils + 1% of reading) |
| Low range resolution | 0.5 µm (0.02 mils) |
| Minimum curvature radius convex | 5 mm (0.2″) |
| Minimum curvature radius concave | 40 mm (1.60″) |
| Minimum measuring area | ⌀ 30 mm (1.20″) |
| Minimum substrate thickness | F: 0.5 mm (0.02″) N: 0.04 mm (0.0016″) |
| Measuring units | Metric/Imperial switchable |
| Calibration modes | 1-point calibration, 2-point calibration |
| Statistics | n, x-, s, Min, Max |
| Operating temperature range | -10 to 60 °C (14 – 140 °F) |
| Storage temperature range | -20 to 70 °C (-4 – 158 °F) |
| Power supply | 1xAA (Mignon)-battery |
| International standards | DIN EN ISO 1461, 2064, 2178, 2360, 2808, 3882, ASTM B 244, B 499, D7091, E 376 |
| Dimensions | Approx. 157 mm length, ⌀ 27 mm (5.2″ length, ⌀ 1.06″) |
| Weight incl. battery | Approx. 80 g (2.8 oz) |
