The DS-2000LED can operate even at the highest flash rates for up to six hours continuously on a single set of three (3) standard “AA” batteries . Keypad controls adjust the flash rate in single increments as well as special keys for 2X and ÷2 functions. Other user-programmable settings include flash duration, phase shift, delay and much more.
Supplied in a high-impact plastic housing with rubber sleeve providing additional protection as well as improved grip for the operator. Lifetime LEDs do not wear-out or need replacement making this product ideal for use on the factory floor, in the field or in the laboratory. Applications include ideal for speed, motion and vibration analysis, on rotating shafts, fans, cams, high-speed motion analysis for speakers or inkjet printing and more.DS-2000LED demonstration video
- Traceable Calibration Certificate provided
- Produces the brightest flash and sharpest image over the entire range to 300,000 FPM
- Lifetime LEDs do not wear-out or need replacement
- Three (3) AA-Batteries provide six hours of continuous use operation
- Market-leading 3000 Lux brightness (measured at 6000 fpm at a distance of 12″)
- Intuitive controls allow user to quickly adjust flash rate and shift phase
- User-selected units of Hz or FPM (Flashes Per Minute)
- IP 65 rated housing provides protection from water jets
- Made in Germany
- 2-Year warranty
Light Output (LUX) vs Distance
at 12″/30 cm Distance, 6000 flashes/min (FPM)
Complete Kit
| Frequency Range | 30 – 300,000 FPM (0.5 – 5000Hz) |
| Flash Duration | Adjustable (1 usec up to 8522 usec) |
| Accuracy | ± 0.02% ± 500ns |
| Resolution | ± 0.1 FPM (30 – 999) ± 1 FPM 1000+ |
| Brightness | 3000 Lux @ 6000 FPM / 30cm (12 inch) |
| Protection Class | IP65 (Protection from Dust and Water Jets) |
| Display | LCD, multiple lines |
| Certification | CE (as per EU norms) |
| Flash Color | Approx. 6.500 K |
| Power Supply | 3x AA size batteries or 3x NiMH rechargeable batteries |
| Housing Material | Aluminum / ABS Heavy duty design |
| Dimensions | 191 x 82 x 60 mm / 7.5 x 3.2 x 2.4 inch |
| Weight Approx | 400g (including batteries) |
| Temperature Range | 0° – 45° C / 32° – 113° F |
| Battery Life | NiMH: approx 11h at 6.000 FPM Disposable: approx 6 h at 6.000 FPM |
| Warranty | 2 Years |
| Default Settings | FPM 1000, Hz 16.6, PULSE µs 333, PULSE deg 2°, DELAY ms 0.0, PHASE deg 0°, DIVIDER 1, OPTION 0 |
