The new LS-3-LED is a high-performance LED stroboscope designed for inspection of webs up to 10″/25cm. Built-in strobe control allows for easy adjustment of flash rate, brightness, phase and more. External input allows syncing the strobe with a remote sensor.The LS-3-LED features a rugged aluminum housing with forty, high-performance LEDs providing a peak brightness of 5000 Lux and convenient adjustment of flash duration to easily select the optimal balance of brightness and image sharpness. It is supplied with a universal battery charger (100-240VAC) with USA, Euro and UK plug adapters. A convenient tripod mount allows for easy installation on a range of equipment.
- 40 High Power LEDs produce 5000 Lux Peak Brightness
- Flash range of 30 – 300,000 fpm (0.5-5000 Hz) with user-selected units of Hz, FPM, 1/MIN
- Adjustable flash duration allows for optimal tuning of brightness and image sharpness
- External trigger input for flash control via external sensor
- Designed for fixed-mounting using 1/4″-20 Tripod Mount or 2 M5 Threaded Inserts
- Supplied with AC-Adapter (100 – 265V AC)
- “Slow Motion” Mode allows user to offset the flash rate to put the “frozen” image into “slow-motion” (External Trigger Mode only)
- “PRO Mode” provides additional functions including Multiplier, Delay and Memory (5 User-set Values)
- Threaded mounting holes for fixed mount applications
- CE Certified with 1-Year Warranty
- Options include Screw-On Handle for Hand-Held use, Strobe Guards for added protection and foam-fitted plastic carrying case
| Model | LEDs | Array Size | Brightness (peak) | Housing Width |
|---|---|---|---|---|
| LS-3-LED | 40 | 10 x 4 | 5000 Lux | 150 mm (6 inch) |
| LS-5-LED | 80 | 10 x 8 | 6000 Lux | 150 mm (6 inch) |
| LS-9-LED | 120 | 15 x 8 | 7500 Lux | 230 mm (9 inch) |
| LS-9-LED-WB | 120 | 5 x 8 (3x) | 7500 Lux | 440 mm (17 inch) |
| LS-18-LED | 200 | 25 x 8 | 9000 Lux | 440 mm (17 inch) |
| LS-36-LED | 480 | 60 x 8 | 14000 Lux | 948 mm (37 inch) |
The LS-3-LED is supplied with the strobe, universal AC adapter with USA, EURO and UK plugs and DIN Connector (for use when externally triggering from sensor).
| LEDs | 40 Hi-Powered LEDs in a 5×8 array |
| Frequency Range | 30 – 300,000 FPM (0.5 – 5000Hz) |
| Flash Duration | Adjustable (1 usec up to 2000 usec) |
| Accuracy | ± 0.02% (± 1-digit/±0.025usec) |
| Resolution | ± 0.1 FPM (30 – 999) ± 1 FPM (1000 – 9999) ± 10 FPM (10,000-300,000) |
| Brightness | 5000 Lux @ 6000 FPM / 30cm (12 inch) – and 3° Sharpness |
| Flash Color | Approx. 5,000 – 8000 K |
| Display | LCD, multiple lines |
| External Trigger Input | 3…30 V / max. 5 mA Potential-free optocoupler DIN 41524 5-pin standard plug Uout = Uin, max. 200 mA switchable trigger input |
| Trigger Output | not available |
| Material | Aluminum |
| Housing Protection | IP30 |
| Dimensions | 6.0″ x 5.1″ x 4.4″ (150 x 130 x 112mm) |
| Weight | 2.09 lbs |
| Ambient temperature | 0°…40°C (32°…114°F) |
| Storage temperature | -25°C…70°C (-10°…125°F) |
| Humidity | max. 95% not condensing |
| Certifications | Certificate of CE conformity |
| Warranty | 1 Year |
| Mounting Holes | Located on underside of housing: (1) 1/4 – 20UNC in center (2) M5 Threaded Inserts (60 mm c:c) outer |
| Power | 24V DC supplied via Universal AC Wall Plug Adapter (100-240V AC), supplied with USA, Euro and UK Plug Adapters |
| Default Settings | FREQUENCY=1000 FPM, BRIGHT=1°/166usec, PHASE=0, TRIGGER=INT, Display Units=FPM, Miltiplier=x1, Bright Units=deg, Delay=0msec, Divider=1, Slow=0, Trigger=0(rising) |
